NCHR数字化系列现场混装乳化炸药车
Site mixed and charged emulsion explosive truck of NCHR digital series

发布时间:2020-04-09 人气:405
产品介绍

该车广泛适用于冶金、煤炭、化工、建材等部门,大中型露天采场装填有水炮孔作业,炮孔的直径在100mm以上。NCHR系列乳化炸药现场混装炸药车可现场混制纯乳化炸药和最多加30%干料的系列乳化炸药。水相、油相、敏化剂的配制在地面站进行,而乳胶基质的乳化可以在地面完成,也可在车上完成,干料的混合、敏化在车上进行。启动取力器,把输药软管伸入孔底,在计数器上输入炮孔的装药量,按下启动按钮,各配料和混制机构开始工作。将输药软管慢慢提起,炸药装在了水的下面,水被排出炮孔。炸药装完后,移到下一个炮孔,重复以上程序,对下一个炮孔装药。

输药效率200——280kg/min。

目前有8T、12T、15T、20T、25T五个规格。

计量误差≤±2%

This truck is widely used in metallurgy, coal, chemicals, building materials and other departments. Large and medium sized open pit is conducted with water hole balasting operation. The hole diameter is more than 100mm.

Emulsified explosive truck with on-site mixing loading of NCHR line can mix pure emulsion explosives and series emulsion explosive with 30% of dry mix at most on-site. The preparation of aqueous phase, oil phase and sensitizer is operated on ground station, while latex matrix emulsion can be completed on the ground, or in truck. Dry material mixture and sensitization is conducted in truck.

Before charging, at ground station, relevant materials should be added into corresponding container in the truck.

When loading truck comes tojob site, start PTO, stretch charging tube into bottom of the hole, input explosive load on counter and press start button. Then, each prepartion and mixing unit begins to work. Slowly raise charg-ing tube. Explosive ischarged below water, and water is discharged from hole. After charging, move to thenext hole, reperat the abouve provedure, and charge the next hole.

Charging effectiveness 200-280kg/min.

Currently, there are 5 specifications, 8T, 12T, 15T, 20T, 25T.

Measurement error ± 2%
